Precision Ceramics

The precision ceramics produced by Ferrotec(China) is mainly sintered by materials with high melting point like oxides, carbides and nitrides. The raw material is the chemical material made from serials of synthetic or refined process, which is made of ultra-fine powder (submicron and nanometer powder) sintered by ultra-high temperature and high pressure.

Precision ceramics Category

Ferrotec ceramic products are mainly made of five types of sintered materials, including silicon carbide ceramics, aluminum nitride ceramics, aluminum trioxide ceramics, silicon nitride ceramics and zirconia ceramics. Each type of product has its own superior characteristics in mechanical, thermal and electrical properties.

SiC ceramic

Silicon carbide is not only the material that is second only to diamond in hardness, but also has better heat resistance and wear resistance than other ceramic materials. Silicon carbide belongs to high temperature structural materials. Even at extremely high temperature (1700℃), the strength is still maintained,. It is used in many important fields such as semiconductor manufacturing equipment parts, burner nozzle, etc.

Zirconia Ceramic

High purity zirconia ceramics have superior strength and toughness, ultra-high wear resistance and high temperature resistance, and superior acid and alkali corrosion resistance. It is mainly used in the circumstance of high temperature, high PH, and high strength.

Alumina Ceramic

High purity alumina ceramics which are widely used in the industries of semiconductor, medical, liquid crystal and new energy, have good insulation, wear resistance, acid and alkali resistance, high temperature resistance, and high strength. The low LLT high purity alumina ceramics Fettotec developed have superior LLT property, which is ahead of the industry.

Silicon Nitride Ceramic

Compared with Alumina, it has better heat resistance and thermal shock resistance which are widely used as a type of heat resistance complex material in the fields like semiconductor manufacturing equipment parts, burner nozzle and welding fixture, etc.

Aluminum Nitride Ceramic

High-purity aluminum nitride ceramics have superior thermal conductivity, insulation, heat resistance and thermal shock resistance, and can be used as heat-resistant material which is widely used in semiconductor etching equipment.

Data Download

精密陶瓷樣冊(cè)

Download

Tel: 0571-88995910 0571-86802099

E-mail: ceramics@ferrotec.com.cn

Tel: 0571-88995910 0571-86802099

E-mail: ceramics@ferrotec.com.cn

High temperature resistance

Good insulating property

High purity

Corrosion resistance

Wear resistance

Advantages of Ferrotec Precision Ceramics

High temperature resistance; good insulating property; high purity; corrosion resistance; wear resistance. Ferrotec precision ceramicss are sintered by ultra-fine powder which has superior properties even under the extreme circumstance of high temperature or corrosion. It is widely used in semiconductor, solar energy, LED, laser, medical equipment and other high-precision fields.

Matrix diagram of applications in various fields

Display

Optical Fiber Communication

Power Electrons

EV/High-speed Train

Home/Medical Appliance

Other Industry

Semiconductor correlation

Precision Ceramics

Semiconductor etching equipment；

MOCVD equipment；

PECVD equipment；
